Type T PE Insulated/Braided Thermocouple Compensation Cable

Basic Info

Model No.:  T

Product Description

Model NO.: T Conductor Type: Stranded Conductor Material: Cu and CuNi Insulation Material: PE Range of Application: Mine Diameter: 0.2~1.5mm Temperature Range: -200~1200 Trademark: Ualloy Origin: Zhejiang China Type: Insulated Application: Overhead, Heating, Underground Sheath Material: PE Material Shape: Round Wire Certification: ISO9001, CE, RoHS Types: T Samples: Available Specification: 0.2-3.2mm HS Code: 9025900090       type T PE insulated/braided thermocouple compensation cable

     Type T PE Insulated/Braided Thermocouple Compensation Cable

       The products is manufactured according to the standards of GB/T4989-1994 "Compensating Wire for
Thermocouples" and JB/T7495-1994 "Compensating Cable for Thermocouples".
       This kind of products are mainly used as the connect wire in the automatic measure instruments in the
electronic power industry, chemical industry, petroleum industry, metallurgy industry and national
defense industry, etc.
       More details about the product:
Item No. T-PE-PE-0.5R
  Conductor Material   +Cu, -CuNi
  Conductor Dia 0.3mm*7/2
   Insulation material PE
   Insulation color + brown, -white
  Cable Construction   Parallel
Inner Shielding material /
  Jacket material PE
   Jacket color brown
  Outer Shielding Material  /
Ground wire /
 Cable Dielectric Test   DC.500v
 Net weight 25kg/km

A link to the thermocouple bare wire:

Contact us if you need more details on 500V. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Brown and White、Type T. If these products fail to match your need, please contact us and we would like to provide relevant information.
